How to make a warm floor from heating? Warm floor water. Installation of heated floor

In contrast to the usual radiator heating, water began to come into vogue relatively recently. This system is designed to heat the floor in both a private house and an apartment. It is used at the same time as a radiator and heat accumulator. It is able to evenly distribute all the generated thermal energy, as well as significantly save on it. Many are already thinking about how to make a warm floor from heating.

Application tips

First of all, you need to figure out where you can install underfloor heating. Most often it is mounted in country houses, due to two main reasons. And the first of them - in apartments that are connected to central heating systems, the installation of heated floors is usually prohibited. This is explained by the fact that there is a threat of increasing hydraulic resistance.

The second reason is that if you connect to the centralized heating system, the water, passing through all the pipes of the heated floor, will return to the common riser already almost cold.

Considering these nuances, in apartments it is best to use electric floor heating, and in country houses - on the contrary, water. In addition, experts recommend the use of the latter only in insulated buildings or premises.

Warm floor in the apartment

Many experts do not advise to do water floors in high-rise buildings. But still, some of them say that there is an exception to the rules.

Warm floor water

How to make a warm floor from the heating in the apartment without harming the neighbors? Nothing is simpler, but this applies only to housing on the ground (with the upper wiring) or the top floor (with the lower wiring of hot water). The fact is that in these apartments the water goes to the return and it is quite suitable for floor heating, while the heat in other apartments does not decrease.

There is one more heating scheme with warm floors, not infringing on the interests of other users. It can be applied in the combined bathroom or in the bathroom. But in this case, no adjustment of temperature is out of the question.It directly depends only on water in the network of central heating, and if the latter is too hot, then the floors will warm up accordingly.

Benefits

The use of underfloor heating in apartments and especially in private homes has many advantages compared with a conventional radiator. The first of them and, perhaps, the most important thing is the most comfortable climate in the house. Uniform warming of the air in the room across the entire surface of the floor almost completely eliminates the risk of colds. The heat emanating from it, does not allow supercool legs.

Warm floor water makes it possible to expand the space of the room due to the removal of radiators from under the windows. This system is completely hidden under the flooring, does not take place, and also allows you to make the window in the whole wall.

Underfloor heating from central heating

It can significantly reduce operating costs, as reducing the temperature by 2 or 3 degrees will not entail any physical discomfort. In addition, the heating system "warm floor" evenly heats the entire room, without creating a cooled or overheated zones.

The next advantage is the absence of so-called convection currents. The radiator heating system acts in this way - the air is heated, which rises and remains under the ceiling, and when it cools near the opposite wall, it descends to the floor. This is how the constant air cycle takes place, raising and carrying a lot of fine dust.

It should be noted that the warm floor water is extremely reliable and safe system in terms of operation. Rather simple design and well-developed technology of creation and installation allows it to serve faithfully for at least 50 years, and this without additional maintenance.

Project implementation

Underfloor heating, where the source of heating is water, is considered a low-temperature heating device. The maximum heating of the liquid in such a system is no more than 55 С. And if we consider that water pipes are not only under a layer of concrete solution, but also of a finishing material, then there will be only 35 ° C on the floor surface. This temperature is enough to feel comfortable.But at higher rates, discomfort will begin to arise when the skin of your feet touches a too hot coating.

Connecting a warm floor to the boiler

Water heated floors - it is always convenient and comfortable. Especially if you do not need to install a water heating boiler. In private houses and apartments with existing radiators you can make a warm floor from the central heating. For this it is necessary to fulfill a number of conditions.

In any case, the heating system must be equipped with a circulation pump. If it is still not there, then it is best to purchase and install it, than to make a gravitational structure with a certain slope of the floor surface. The system can be of two types: one-pipe or two-pipe. In the first case, the supply pipe is connected after the circulation pump, and the return - before the pump.

In addition, it is necessary to calculate the length of the contours. For a single-pipe type, it should not exceed 30 m, and for a two-pipe one - 50 m. It happens that the contour is longer, then it is divided into several parts and placed in parallel or in different zones.

Required items

Heating systems, where it is provided to connect a heated floor to the boiler, should consist of several basic elements:

● metal or polymer pipes;

● circulation pump;

● heat insulation materials;

● heating boiler;

● fasteners, headers and fittings;

● control valves and shut-off ball valves.

Such a heating system can not only be mounted independently, but also made preliminary calculations. If the main source of heat is only water floor, then the project is better to order from the experts.

Species

Water heating, which is installed on the plane, can be concrete and flat. The first type involves the installation of a heated floor with the use of a concrete screed, and the second - without it. Nesting should be laid on special plates of aluminum, pre-coated with polystyrene gasket, or on a wooden floor, as well as on pre-installed logs. But the concrete screed is still more common and popular.

Connection

The simplest connection scheme for a heated floor should look like this: the first collector connects the water supply pipelines, and the second, in turn, retraces. They are connected to the pipes with the coolant itself. This option has one major drawback - it is simply impossible to regulate the temperature of the water coming from the boiler.

The maximum that can be done is to shut off the valves, but this does not solve the problem itself. It is known that some floor decorative coatings deteriorate if they are heated to more than 30 ⁰С. Therefore, it is advisable to provide for temperature adjustment.

How to make a warm floor from heating

In order for a warm floor connection scheme to be complete, it is necessary to add several additional elements, such as a three-way mixer or pump-mixing unit, a circular pump, an air vent and a drain valve.

In addition, instead of shut-off valves, it is better to install thermostatic faucets. Due to the change in the size of the rod with paraffin, it allows the bandwidth of the crane to function without sudden drops.

The presence in the scheme of the pumping and mixing unit is also necessary. It adds chilled water to the supply when it is necessary to lower its overall temperature so that it does not exceed the permissible norms.

It is worth paying special attention to the installation of the mixing pump. It must be between the supply line and the supply manifold. To its third outlet connect the conclusion of the liquid from the giving collector.This allows the pump to take part of the chilled water and add it to the flow.

Installation procedure

Before you begin to work on the installation of the system, you need to know the sequence of how to make a warm floor from the heating according to all existing rules.

The installation procedure consists of several basic steps:

● establishment of a collector group;

● leveling the surface of the floor and its preliminary preparation;

● laying pipelines of the future heating system;

● temperature control.

Collector group

Work on the installation of floor water heating starts with the installation of a collector cabinet, which should be located at the same distance from the end users. For example, if a warm floor will be located in the territory of two rooms, then the box must be placed in the middle between them.

In order to collector cabinet does not spoil the interior of the room, it is hidden inside the wall. During the preparatory activities make a special niche with a grinder or perforator. Its size should be slightly larger than the dimensions of the cabinet, and should be placed near the floor.

Wiring the floor heating

Auxiliary water floor system consists of a certain number of pipelines. They are joined in a manifold cabinet and drawn from the main heating system. In the box must be both shut-off and control valves.

After the installation of the collector cabinet, the supply and return pipelines are brought into it. On the first there is hot water from the central system, and on the second - already cooled back. At the ends of these pipelines, stop valves are installed in the form of valves or ball valves, which can be used to turn off the water supply at the right time. The transition between them is a special compression fitting.

All components of the collector cabinet are connected to the rail with outlet nozzles, to which the pipes forming the contour are pulled. As can be seen in the photo, the scheme of connecting a heated floor is quite simple, so it can be done without the help of a specialist.

Preliminary floor preparation

First of all, it is necessary to check the horizontal plane on which the heating system will be located. Heat-insulated floor of water is placed only on a previously prepared and leveled surface. And this stage of work should not be neglected.The uniformity of heating directly depends on the same layer of the screed over the entire surface of the floor.

Heating underfloor water

After leveling, proceed to the laying of the waterproofing layer. Then a special damping tape is glued to the walls around the perimeter of the room, which can compensate for linear expansion of the screed or underfloor heating. Excess it is cut off.

Mounted heating "warm floor (water)" only with the use of insulating mats made from materials such as aerated concrete, bicycle thermal, technical cork, mineral wool or polystyrene foam. They prevent heat loss.

Installation

At this stage, they are engaged in fixing the pipelines of the thermal circuit. The most popular method is laying and fixing pipes to a special masonry grid made of metal and laid on insulation. Fix on it the pipeline with the help of knitting wire.

Installation of heated floor

In the event that the thermal circuit exceeds a length of 70 m, then a second one is made. The pipeline is always carried out according to this principle - from the colder ones (windows and doorways) to the warmest zones.

Check

Hydraulic tests of already laid pipes are carried out only before they start to fill them with cement-sand mortar.They are considered successful if there are no leaks in the pipeline at a water pressure of 6 atmospheres. The time required for complete drying of the concrete floor is not less than 10 days. Only if all the conditions of installation are met, water heating will be as efficient, reliable and durable as possible.

Adjustment

The temperature of the water floor heating can be adjusted in two ways: manual and automatic. The first is carried out using a ball valve, and the second - by electric drives. I must say that the most effective with water heating is exactly automatic adjustment.

When building a new house inevitably raises the question of what kind of heating to choose. Taking into account all the pros and cons of various types of heating, it is possible to come to the only correct decision that a better system than underfloor heating is simply not found. In addition, it can be connected to almost any heat source using different energy sources. And since it is not difficult to make a heated floor from the heating itself, you can also save a decent amount of money.
